MODULA RIG: OVERVIEW

Compact High-Speed Unit

The Ulti-Head it is designed to be the ultimate in low-cost yet precise and portable motion control head. But now it is even more versatile as it is specifically designed to be a very modular motion control system with easy addition of extra axes of motion. In particular, the axis of Track adds a tremendous degree of freedom to the Ulti-head and any shoot.

By adding a high-speed track motor and dolly system, as well as some industry standard rails, a whole new range of shots can be accommodated for very little additional cost. As an added benefit the track axis is “back-driveable” meaning that it can be pushed manually to record the motion**, just like a normal dolly, and then the motion can be repeatedly played back as often as required, or even the data exported to CGI.

There are a number of options for the Track system including:

• The choice of Rack & Pinion drive for optimum accuracy and rigidity, or Belt & Pulley for optimum cost and track compatibility.
• Uprated Track drive for speeds in excess of 4 metres/sec
• Battery driven capability for the track system.
• Choice of Straight or Curved racking for track rails.
• Precision Bearing Rail instead of industry standard dolly rail for the Ultimate in performance.

The UltiHead and any additional axes, like the Track, can be controlled using remote hand-wheels, joysticks, or pan-bars. Alternatively it can be programmed from the keyboard and mouse, using the advanced Flair software system with a highly graphical and user friendly interface. Flair also gives the operator the ability to pre-visualise the move both numerically and graphically and make adjustments as necessary before committing to the action run, as well as importing and exporting moves to CGI, such as XSi, Maya or Filmbox.

If the system is not required for motion control but simply as a remote system then it can easily be connected to the MSA-20 Handwheel or Joystick controller instead of Flair. This gives the ability to operate or dry-hire the system with little or no training as the operation is so simple and intuitive.

This awesome system boasts several key features to set it apart from anything else currently available on the market, including:

• Extremely high accuracy and rigidity for use in motion control applications
• Very high speed of movement
• Space-saving compact design for high portability
• Very Low-cost
• Fully adjustable for any camera or lens
• Runs from the award winning Flair motion control system
• Designed for Film, Video and HD cameras
• Works directly with the MSA-20 for Remote head use
• Track, Lift and Roll options

For more information please contact [email protected]

** requires Flair for this function to operate

Add vertical motion

The Ulti-Head it is designed to be the ultimate in low-cost yet precise and portable motion control head. But now it is even more versatile as it is specifically designed to be a very modular motion control system with easy addition of extra axes of motion. In particular, the axis of Track & Lift add a tremendous degree of freedom to the Ulti-head and any shoot.

By adding a high-speed track motor and dolly system, a very sturdy telescopic lift mechanism, as well as some bearing rails, a whole new range of shots can be accommodated for very little additional cost. As an added benefit the track axis is “back-driveable” meaning that it can be pushed manually to record the motion**, just like a normal dolly, and then the motion can be repeatedly played back as often as required, or even the data exported to CGI.

The Lift option for the Modula rig provides:

• 2.5 feet of vertical travel.
• Strength to carry heavy payloads, whether a full film camera package or a 3D Stereoscopic rig
• High speed vertical motion, with absolute frame accuracy at any speed.
• The option to add a full jib arm and rotate mechanism.
• Together with the Track, the Modula rig with Lift can do a wide range of different shots at speeds in excess of 3 metres/sec
• Full control of lens functions such as focus, zoom and iris.

The UltiHead and any additional axes, like the Track & Lift, can be controlled using remote hand-wheels, joysticks, or pan-bars. Alternatively it can be programmed from the keyboard and mouse using the advanced Flair software system with a highly graphical and user friendly interface. Flair also gives the operator the ability to pre-visualise the move both numerically and graphically and make adjustments as necessary before committing to the action run, as well as importing and exporting moves to CGI, such as XSi, Maya or Filmbox.

This awesome system boasts several key features to set it apart from anything else currently available on the market, including:

• Extremely high accuracy and rigidity for use in motion control applications
• Very high speed of movement
• Space-saving compact design for high portability
• Fast return on investment
• Fully adjustable for any camera or lens
• Runs from the award winning Flair motion control system
• Designed for Film, Video and HD cameras
• Head works directly with the MSA-20 Handwheels or Panbars for Remote head use or dry-hire
• Roll option

For more information please contact [email protected]

** requires Flair for this function to operate

Full motion control system

The Full Modula rig is designed to make full use of its modularity by enabling the user to adapt it to any shoot, whether the requirement is something very fast and compact to quickly follow some action or be very portable, or whether it needs a full jib arm system for filming over a product. The Modula rig uses the Ulti-head pan tilt moco head as its basis and then builds up from there.

The Ulti-Head it is designed to be the ultimate in low-cost yet precise and portable motion control head. But now it is even more versatile as it is specifically designed to be a very modular motion control system with easy addition of extra axes of motion. In particular by adding the axes of Track, Lift and Rotate when needed, they can add a tremendous degree of freedom to the Ulti-head and any shoot.

By adding a high-speed track motor and dolly system, a very sturdy telescopic lift mechanism, and a jib arm (with motorized rotate mechanism), a whole new range of shots can be accommodated. As an added benefit the track axis is “back-driveable” meaning that it can be pushed manually to record the motion**, just like a normal dolly, and then the motion can be repeatedly played back as often as required, or even the data exported to CGI.

The full Modula rig provides:

• 6 feet of vertical travel.
• Strength to carry heavy payloads, whether a full film camera package or a 3D Stereoscopic rig
• High speed vertical motion, with absolute frame accuracy at any speed.
• A full jib arm and rotate mechanism to get over or under the subject of interest.
• A wide range of different shots at speeds in excess of 3 metres/sec
• Full control of lens functions such as focus, zoom and iris.
• An optional Roll axis
• Unlimited length of track (subject to cable lengths)

The UltiHead and any additional axes, can be controlled using remote hand-wheels, joysticks, or pan-bars. Alternatively it can be programmed from the keyboard and mouse using the advanced Flair software system with a highly graphical and user friendly interface. Flair also gives the operator the ability to pre-visualise the move both numerically and graphically and make adjustments as necessary before committing to the action run, as well as importing and exporting moves to CGI, such as XSi, Maya or Filmbox.

This awesome system boasts several key features to set it apart from anything else currently available on the market, including:

• Extremely high accuracy and rigidity for use in motion control applications
• Very high speed of movement
• Space-saving compact design for high portability
• Fast return on investment
• Fully adjustable for any camera or lens
• Runs from the award winning Flair motion control system
• Designed for Film, Video and HD cameras
• Head works directly with the MSA-20 Handwheels or Panbars for Remote head use or dry-hire
• Roll option

For more information please contact [email protected]

** requires Flair for this function to operate
